BE 6.5 Cfm @ 90 Psi - 5 Gallon Portable Electric Air Compressor AC255
BE 6.5 Cfm @ 90 Psi - 5 Gallon Portable Electric Air Compressor
Heavy-duty, splash lubricated pump with cast iron cylinders and aluminum body for optimum durability and performance. Oversized pump bore improves recovery time and provides higher air output. Pressure switch is set up to cut-in at 105 PSI then cut-off at 135 PSI. Includes regulator to adjust line pressure where it is needed, industrial type couplers, and air gauges. Low profile horizontal 5 gallon tank is protected in a roll cage platform. Lightweight frame with large wheels make it easy to transport. Handles include hooks to hold air hose and can fold down to Unique storage compartment is built into the deck to keep small tools and accessories readily available.
• 3.0 HP motor set up for 120v operation drawing 15 amps. • Heavy-duty, splash lubricated pump with cast iron cylinders and aluminum body for optimum durability and performance. • Oversized pump bore improves recovery time and provides higher air output. • Pressure switch is set up to cut-in at 105 PSI then cut-off at 135 PSI. • Includes regulator to adjust line pressure where it is needed, industrial type couplers, and air gauges. • Low profile horizontal 5 gallon tank is protected in a roll cage platform. • Lightweight frame with large wheels make it easy to transport. • Handles include hooks to hold air hose and can fold down to minimize profile for storage. • Unique storage compartment is built into the deck to keep small tools and accessories readily available.
- HORSE POWER: 3.0
- AMPS: 15
- VOLTS: 120
- POWER CORD: 6’
- DUTY CYCLE: 100%
- RPM 3400
- TANK SIZE: 5 GALLONS
- MATERIAL: POWDER COATED STEEL
- FITTINGS: 2 INDUSTRIAL COUPLERS
- TANK DRAIN: BALL VALVE
- WHEELS: 10” FLAT FREE
- TYPE: RECIPROCATING
- MAX PSI 135
- STAGE: SINGLE
- OIL TYPE: 30W NON-DETERGENT
- DUTY CYCLE: 75%
- RPM: 3400
- AIR FILTER: 1/2” NPT PORT SIZE
- PART NUMBER: 42.012.025
- LxWxH: 24" x 20" x 21"
- WEIGHT: 110 LBS
